13. Installing the Fiery software for Windows and Macintosh

Xerox Phaser 790

13–11

6. Select Apply to accept the changes to the My Fiery List.

7. Select OK.

Configuring the connection for Fiery Link using an Advanced

Subnet search

1. Select the AutoSearch tab.

2. Select the Advanced button and the Subnet Addr tab.
