5. Connecting to the network

Xerox Phaser 790

5–9

Windows computers using Windows printing

Another

supported

protocol

Printer

TCP/IP (nbt) protocol

Windows

workstation

For Windows printing:

Windows 95/98 and NT 4.0

workstations

Window (SMB) printing enabled

TCP/IP (nbt)

Windows

workstation

Windows

workstation
