Clearing Area 3 jams 23. Problem Solving

Xerox Phaser 790 23-13

Clearing Area 3 jams

Perform this procedure when the message Clear Jam in Area 3 is displayed

on the Control Panel.

1. Open the Area 3 access door.

301099

2. Remove any jammed or torn paper as shown below. Ensure that there

are no pieces of torn paper remaining in the feed area.

301100

3. Close the access door.

W O
