16. Introduction to the Command WorkStation
Xerox Phaser 790
16–9
The Command WorkStation interface
The display illustrated below is the default Command WorkStation
display in the middle of job processing. There are two other windows,
Archive and Job Log, which you access via tabs at the bottom of the
display (3). The elements numbered 1 through 4 are common to all
Command WorkStation displays, those numbered 5 through 7 appear
only in the Queues window, and element number 8 is common to the
Queues and Archive windows.
1 Server selection tabs
2 Sliders and system information
3 Window selection tabs
4 Job ticket information
5–7 Queues window display
8 Thumbnail tabs
1
4
5
2 6
7
3
8
