Xerox Phaser 790 2-1
Getting to know the Phaser 790
301074B-WOL
0
Printer, Front View
1. Paper Tray 1 – place copy paper here
2. Duplex Tray – option that allows two-sided printing
3. Front Cover – open to access the Dry Ink Cartridges and the Copy/Print
Cartridge
4. Control Panel – use to access the Printer menus and to view messages
5. Output Tray – the prints are delivered here
6. Paper Stop – use to stop oversized prints from being pushed out of the
Output Tray. The Paper Stop is adjustable up to 17 x 11 inch (B4)
paper.
7. Top Right-hand Cover – open to add additional memory
8. Bypass Tray – use for transparencies, envelopes, postcards, or other
stock
9. Bypass Transport – open to access paper jams
10. Paper Feed Area – open to access paper jams
1
3
4
5
6
7
10
9
8
2
2
