9. Installing user software in a Windows 95/98 environment

Xerox Phaser 790

9–14

Setting up IPX/SPX printing with Windows 95/98

To print from Windows 95/98 workstations over IPX (Novell), you must

first set up IPX/SPX protocols, and then configure the printer by

selecting the IPX port type and entering the settings for the port you

use.

1. Select the Start button, Settings, and Control Panel.

2. Double-click the Network icon.

Ensure that an entry for IPX/SPX-compatible Protocol is listed in

the Installed Network Components section. For additional

information, refer to the Windows 95/98 documentation.

3. Double-click the IPX/SPX-compatible Protocol icon.
