2. Setting up the Phaser 790 Getting to know the Phaser 790

2-2 Xerox Phaser 790

301075B-WOL

Printer, Rear View

11. Area 4 access cover – open to access A4 paper jams

12. Side Output Tray – copies are delivered to this tray

13. Printer Power Switch – use to switch OFF and ON the Printer power

14. Printer power cord jack – connect the Printer power cord here

Default Chapter1
