5. Connecting to the network

Xerox Phaser 790

5–6

Mac OS environment with AppleTalk

Mac OS workstation

Printer

AppleTalk

Mac OS workstations can print

directly and use Fiery utilities

Mac OS workstation

Mac OS workstation

AppleTalk protocol

Another

supported

protocol
