13. Installing the Fiery software for Windows and Macintosh

Xerox Phaser 790

13–13

4. Select Search.

When the search is complete, all found printers are displayed in

the Available Fierys area of the dialog box.

If the printer was not found and you would like to search again

using the same parameters, select Refresh.

Only printers that support Fiery Link are displayed in the Available Fierys

area.
