14. Printing from the Windows workstations

Xerox Phaser 790

14–8

6. Select OK.

Depending on the application, you will see one of two dialog

boxes.

7. Select OK, then OK again to print; or, if the Print button is

available, select Print.

The job prints with the specified settings.
