1. Setting up the Phaser 790 Unpacking the Printer
1-14 Xerox Phaser 790
WARNING
Ensure that you have a firm footing and bend your knees to avoid possible
back injuries. When lifting the Printer, face the machine and grip the
recessed areas shown in the illustration below.
NEVER lift the Printer by gripping any other area. The Printer could fall and
cause injuries.
5. With a person at each corner, place your hands inside the plastic wrap,
in the positions shown below.
CAUTION
DO NOT lift or support the Printer by the Bypass Tray that is located on the
right-hand side.
6. Carefully, lift the Printer from the pallet.
7. Perform one of the following steps:
• If you are installing the Phaser 790 on the optional Printer Cabinet,
go to step 8 on the next page.
• If you are installing the Phaser 790 on the optional 2 Tray Module,
skip step 8 and go to step 9.
• If you did not order one of the above options, skip steps 8 and 9
and go to step 10.
To Next Page
