24. Maintenance Replacing the Dry Ink Container

24-14 Xerox Phaser 790

5. Place the used container in the box and discard.

WARNING

DO NOT dispose of used Waste Containers in an open flame. Used Dry Ink

could explode and cause burns.

6. Push the new Waste Container into the Printer until it clicks into place.

7. Close the Front Cover.

301077b
