PSM-AC6
PSM-AC6
Overview 103
Features 104
Specifications 104
Overview
The SH12 supports up to four AC power supply modules (PSM-AC6) installed at the
bottom of the shelf.
Figure 36: PSM-AC6 Faceplate
Parameter Value Notes
Sales item number 1040800066-01
Release introduced FSP3000R7 Release 17.1
Compatible shelves SH12
Width 108 mm (4.3 in.)
Height 40.8 mm (1.6 in.)
Weight 1.3 kg (2.8 lbs)
Power connector IEC-320-C20 male
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
l IEC 60529 IP20 (indoor office)
Table 39: General Information — PSM-AC6
103 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
