Required Tools and Equipment
EQUIPMENT DAMAGE MAY RESULT IF AN SH4R OR SH4R-2
IS INSTALLED IN A TWO-POST NON-ETSI RACK.
The depth and weight of a populated shelf might cause structural and
mounting bracket damage. Additionally, its instability might cause it
to fall and become damaged. For non-ETSI configurations, you must
install the SH4R and SH4R-2 in a four-post rack (with the guide rail
kit).
EQUIPMENT DAMAGE MAY RESULT IF AN SH1R IS
INSTALLED IN A TWO-POST RACK (WITHOUT THE MID-
MOUNT BRACKETS).
The depth and weight of a populated shelf might cause structural and
mounting bracket damage. Additionally, its instability might cause it
to fall and become damaged.
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Rack (used in previous procedure)
l Rack screws and cage nuts for attaching the shelf to the rack
l Appropriate guide rail kit (for SH4R and SH4R-2)
l Appropriate guide rail kit (for SH1R installed in four-post racks)
l Pozidriv or Phillips screwdriver
l 1 x cage nut in conjunction with a Pozi screw (both included in with the
ADVAgrounding cable) to attach the grounding cable to the rack (if applicable)
l Multimeter (for testing grounding cable)
l Installation Overview — SH12 Shelf
l Installation Overview — SH4R and SH4R-2 Shelves
l Installation Overview — SH1R Shelf
l Installation Overview — 1U Shelf
l Guide Rail Kits
l Racks
l Rack-Mounting Requirements and Warnings
l Site Preparation Checklist
l Electrostatic Discharge Damage Prevention and Warning
