Prerequisites for Connecting the AC Power
Prerequisites for Connecting the AC Power
l The site wiring systems must be installed in accordance with your national and local
electrical safety standards.
l Site wiring must include a protective ground connection to the ACpower source.
l The ACPSM should be the only appliance in the supply circuit.
l Each PSMmust use a separate AC power source outlet, maintaining power
redundancy.
l The dedicated power source outlets are easily accessible and located close to the
PSMs. The supplied AC power cables are approximately 2.5 m (8.203 ft) long.
l The line voltage and frequency to be used are the same as indicated on the shelf
supply values label located on each shelf.
l The plug-socket combinations must be accessible at all times, because they serve as
the main disconnecting device in case of an emergency.
l AC Power Cable Specifications
l AC Power Source Requirements
l General Power and Grounding Guidelines
l Site Planning and Preparation
l Connecting ACPower to theSH12 Shelf
l Connecting ACPower to theSH4R and SH4R-2 Shelf
l Connecting AC and DCPower to theSH4R and SH4R-2 Shelf
l Connecting ACPower to theSH1R Shelf
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 322
