Overview
Chapter 15
Unpacking and Inspecting the Shelves
and Components
Overview 242
Best Practices 243
Required Tools and Equipment 244
Unpacking an SH12 Shelf 245
Unpacking an SH4R and SH4R-2 Shelf 247
Unpacking an SH1R Shelf 250
Unpacking a 1UShelf 252
Inspecting the HD Equipment 253
Overview
Depending on what you ordered, a complete HD system shipment can consist of multiple
boxes. All boxes are equipped with a summary of contents, as well as the total number of
boxes shipped (if applicable).
Due to weight, the SH12 is normally shipped empty. The SH4R, SH4R-2, and SH1R are
shipped either empty or equipped, depending on how you ordered it. Each HD shelf ships
with the appropriate accessories and companion documentation.
This table provides the approximate dimensions and average weight of the shipping
boxes (with the shelves shipping empty).
Shelf Outer Dimensions (H x W x D) Weight
SH12 720 x 488 x 604 mm (28.4 x 19.2 x 23.8
in.)
41.7 kg (91.8 lbs)
SH4Rand
SH4R-2
330 x 590 x 750 mm (13.0 x 23.2 x 29.5
in.)
34.8 kg (76.7 lbs)
SH1R 746 x 564 x 190 mm (29.4 x 22.2 x 7.5 in.) 6.7kg (14.8 lbs)
TR1 590 x 400 x 150 mm (23.2 x 15.7 x5.9 in.) 2.9kg (6.4lbs)
Individual modules of any type, spare parts, and replacement parts or other equipment
are shipped in separate boxes.
