Mounting the SH1R Shelf to a Rack
Mounting the SH1R Shelf to a Rack
LIFTINGHAZARD CAUTION
ADVA Optical Networking recommends having two people hold the shelf
in place while a third person secures it to the rack. When carrying and
mounting the SH1R, use the handles present on the mounting brackets.
This procedure assumes that:
l For 23-inch and ETSI four-post rack configurations, the mounting
brackets are attached to the guide rails;
l For two-post rack configurations, the mounting brackets are attached
to the shelf; and
l The grounding cable is installed to the shelf.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. On the rack mounting rails, locate and mark the mounting holes where you will mount
the shelf.
3. For a 23-inch or ETSI four-post rack installation, install four cage nuts in the
corresponding holes on each side of the rack. No cage nut is needed for a 19-inch
rack installation.
4. If there is a terminal connector used for the ground point preinstalled in your rack,
skip this step and proceed to the next step. Otherwise, locate and clip the cage nut to
the right mounting rail on the back side of the rack for the grounding cable to be
attached.
5. For a four-post rack installation:
a. Use a Phillips screwdriver and four M6x12 screws to attach the left guide rail to
the rack.
b. Use a Phillips screwdriver and four M6x12 to attach the right guide rail to the rack.
c. Lift the shelf to the bay and slide it into the guide rails so that the bracket holes on
each side are aligned with the rack mounting holes on the guide rails.
d. Use a Phillips screwdriver and one M6x12 screw to attach the left guide rail to the
shelf.
e. Use a Phillips screwdriver and one M6x12 screw to attach the right guide rail to
the shelf.
