Adva 3000R7 - MPO24 to 24 LC Breakout Cables

Fiber Optic Cables and Accessories
MPO24 to 24 LCBreakout Cables
These variants are available for the MPO24-24LCbreakout cables.
Item Description Sales Item
Number
Optical
Connectors
Fiber
Type
Overall
Length
Breakout
Length
Trunk
Length
JZ/SM/MPO24-
24LC/0300
1051002610
l 1 x MPO24
l 24 x LC/PC
Single-
mode
3 m (9.8 ft) 1 m (3.3 ft) 2 m (6.6 ft)
JZ/SM/MPO24-
24LC/1000
1051002611
l 1 x MPO24
l 24 x LC/PC
Single-
mode
10 m (32.8
ft)
1 m (3.3 ft) 9 m (29.5
ft)
Figure 64: MPO24-24LC Breakout Cable — Fiber and Port Reference
MPO24 Port MPOPort Description LCPort Description
1 Tx1 Rx1
2 Tx2 Rx2
231 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
