SH4R Shelf
For DCpower, redundant A- and B-battery feeds provide the shelf power with an input of
–48 VDC . The power feeds are located on the bottom rear of the shelf. Each power
supply has its own A and B backplane feed. Each input feed has its own –48 V fail
detection.
For ACpower, the AC power cables connect directly to the front of the power supply at
the rear side of the shelf.
l AC Power Source Requirements
l DCPower Source Requirements
l General Power and Grounding Guidelines
l Electrical Safety Guidelines and Warnings
l PSM-AC4
l PSM-AC5
l PSM-DC4
Grounding
The SH4R contains these ground terminals and connectors:
l Chassis ground
l Signal ground
l Strap for a 2-zone or 3-zone configuration
l ESD ground
The signal ground and 3-zone ground configuration are currently not
supported.
