Installing the ECM
Installing the ECM
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module are properly inspected.
The ECM-2 is installed in the front of the SH12, SH4R, and SH4R-2. The
ECM-3 is installed in the rear of the SH1R.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the ECM with the faceplate toward you and the levers extended.
3. Align the ECM edges with the guides of the shelf slot.
4. Lift out the levers, and then gently apply pressure to the bottom of the faceplate while
you push the module into the slot.
5. Push on the faceplate to fully seat the module.
6. Press down on the locking levers to secure the module and connect it to the
backplane. The module is completely inserted when its faceplate is flush with the
faceplates of the adjacent modules and the shelf panels.
7. After you have completely inserted the ECM , hand-tighten the thumb screws to
prevent inadvertent dislodging.
8. Use a Torx T10 screwdriver to gently tighten the thumb screws. Do not overtighten.
Currently ECM redundancy is not supported. However, a second,
dormant ECM can be installed in the additional slot as a future spare
ECM. The software recognizes the ECM is present without raising
alarms.
l Electrostatic Discharge Damage Prevention and Warning
l ECM-2
l ECM-3
301 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
