Grounding Cables
l Grounding
l General Power and Grounding Guidelines
l Connecting the Grounding Terminals
l Electrical Safety Guidelines and Warnings
Grounding Cable — SH4R and SH4R-2
The SH4R and SH4R-2ships with this grounding cable:
l Shelf grounding cable (CBLZ/GND/0100/1AWG6/TB-A/GN-YL - Sales Item Number
1036800033)— 6 AWG, 100 cm length, green/yellow. Equipment end: 90-degree
angled 2-hole M5 ring lug. Rack end: straight 2-hole M6 ring lug. LSZH compliant.
Appropriate screws and washers are preinstalled on the shelf.
You can also order the grounding cables separately.
l Grounding — SH4R
l Grounding — SH4R-2
l General Power and Grounding Guidelines
l Connecting the Grounding Terminals
l Electrical Safety Guidelines and Warnings
Grounding Cable — SH1R
The SH1R ships with this grounding cable:
l Shelf grounding cable (CBLZ/GND/0100/1AWG10/TB-A/GN-YL) — 10 AWG, 100 cm
length, green/yellow. Equipment end: 90-degree angled 2-hole M5 ring lug. Rack end:
straight 2-hole M6 ring lug. LSZHcompliant. Appropriate screws and washers are
preinstalled on the shelf rear.
l Grounding
l General Power and Grounding Guidelines
l Connecting the Grounding Terminals
l Electrical Safety Guidelines and Warnings
211 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
