QSFP Optical Transceivers
l Overview
l QSFP Optical Transceivers
l Handling Pluggable Transceivers
Management
You can use the management software to obtain information about the pluggable fiber-
optic transceiver, the operating status, and network operating conditions.
l Features
l Features — QSFPOptical Transceivers
QSFP Optical Transceivers
Features 134
Color Coding 135
QSFP10/11G/4LR/SM/MPO 136
QSFP10/43G/LR4/SM/LC 138
QSFP10/43G/SR4/MM/MPO 141
QSFP28/103G/CWDM4/SM/LC 143
QSFP28/103G/LR4/SM/LC 145
QSFP28/103G/PSM4/SM/MPO 147
QSFP28/112G/AOC/xxxx 149
QSFP28/112G/DAC/yy/xxxx 152
QSFP28/112G/LR4/SM/LC 155
QSFP28/112G/PSM4/SM/MPO 157
QSFP28/112G/SR4/MM/MPO 159
Features
l Class 1 Laser safety compliance
l Low EMI metallic enclosure
l Uncooled or cooled laser transmitter, depending on the type
l Transmit disable and loss-of signal functions
l Multi-rate capabilities
l Multi-protocol compliant
l Very low jitter
l Low power dissipation
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 134
