As soon as power is up, the ECM-2 starts booting. The Mod LED of the first PSM
should turn green to indicate that the units are functioning properly.
The FTM-4s should start working, one after another and the Svc LED should turn
green. This also indicates that the FTMs are functioning properly. In addition, the
Mod LEDs of all modules installed in the shelf should turn green.
If the Mod LED of the PSM is off, no power is being supplied to the unit. In
case of an error, the Mod LED turns red. For troubleshooting information,
see Troubleshooting with Component LEDs or contact ADVA Optical
Networking for technical assistance.
l AC Power Source Requirements
l AC Power Cable Specifications
l Electrical Safety Guidelines and Warnings
l In Case of Electrical Accident
l Slot Covers
Connecting ACPower to theSH1R Shelf
ELECTRIC VOLTAGEWARNING
Before connecting the ACpower cable, ensure that power is
removed from the dedicated AC supply circuit.
This procedure assumes that:
l The shelf is properly grounded and mounted in the rack;
l The PSM-AC3s is securely installed in the shelf; and
l The ACpower cable is specific to your country and was provided by
ADVA Optical Networking.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. If the dedicated ACpower source outlet has a power switch, set it to the OFF (0)
position.
3. For the shelf that you want to power, determine which redundant, load-sharing mode
configuration you want to support. This figure details the supported AC power wiring
configuration.
