SH1R Shelf
Overview 64
Features 67
Slot Numbers and Assignments 67
Cooling and Airflow 68
Power 69
Grounding 70
Shipment Contents 70
Overview
The SH1R transport shelf is a rack-mountable chassis that accommodates infrastructure
and optical traffic modules, in addition to accessories from the HD product family.
Figure 17: SH1R Shelf and Components — Front View
Figure 18: SH1R Shelf and Components — Rear View
