SH1R Shelf
Parameter Value Notes
Sales item number 1078800081-01
Release introduced FSP3000R7 Release 17.1
Depth 578 mm (22.8 in.) With rear ACpower cables
Width 447 mm (17.6 in.)
Height
l 1U
l 44.5 mm (1.8 in.)
Weight 8.8 kg (19.4 lbs) Weight includes:
l Three FTM-3s
l One CEM-3
l Two ECM-3s
l Two PSMs
l Slot covers
Number of slots 4
l 2 for management modules
l 2 for traffic modules
Power Power Supply Module
(PSM)
l PSM-AC3
l Supports AC/DC PSMs
o
Up to two PSM-AC3s
l Supports both redundant and
non-redundant configurations
Cooling Fan Tray Module (FTM-3)
l Supports three FTM-3s
Management
l Common Equipment Module (CEM-3)
l Element Controller Module (ECM-3)
Rack format support
l 19-inch
l 23-inch
l ETSI
The mounting brackets are
included in the appropriate guide
rail kit (four-post rack
installation) or mounting bracket
kit (two-post rack installation).
Temperature range 5 to 40°C (41 to 104°F) Long term
–5 to 50°C (23 to 122°F) Short term, testing to 55°C
(131°F)
Limited to 45°C (113°F)short
term when using modules > 120
W per slot
Humidity 85% at 40°C (104°F) Long term
5 to 93% Short term
Altitude 5000 m (16,404.2 ft)
Nominal/rated input voltage 100 to 240 VAC PSM-AC3
Voltage tolerance
l Nominal/Rated:100 to 240 VAC
l Operating: 90 to 264 VAC
PSM-AC3
Table 11: General Information — SH1R
