SH1R Shelf
Parameter Value Notes
Nominal/rated current
l 1+0: 5.4 to 2.2 A @ 100 to 240 VAC
l 1+1: 5.2 to 2.1 A @ 100 to 240 VAC
PSM-AC3
1
Power consumption
(fully equipped with 2 traffic
modules)
360 W @ 100 to 240 VAC Typical (PSM-AC3)
539 W @ 100 to 240 VAC Maximum (PSM-AC3)
Maximum power
1
1+0 (non-redundant) configuration)
l 539 W @ 100 to 240 VAC
l 5.4 A @ 100 VAC
l 4.5 A @ 120 VAC
l 2.2 A @ 240 VAC
PSM-AC3
1+1 (redundant) configuration
l 522 W @ 100 to 240 VAC
l 5.2 A @ 100 VAC
l 4.3 A @ 120 VAC
l 2.1 A @ 240 VAC
Maximum internal power
l 1+0 and 1+1: 480 W
PSM-AC3
Environmental standards
compliance
l Telcordia SR-3580 Level 3
(NEBS)
l ETSI EN 300 019-1-3 Class
3.1
l IEC 60529 IP20 (indoor
office)
Table 11: General Information — SH1R
Slot numbers and identifiers are printed on the front and back of the shelf.
l Environmental Specifications
l Power
l MTBF Hours for HDEquipment
l Infrastructure Modules
l Traffic Module Compatibility
l Accessories
l Installation Overview — SH1R Shelf
1
Calculated without the power factor
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 66
