Fiber Optic Cables and Accessories
Breakout Cables
Overview 229
MPO12 to 8 LCBreakout Cables 230
MPO24 to 24 LCBreakout Cables 231
l Handling Fiber-Optic Cables
l Cable Management Best Practices
l Shelf Cable Capacity
l Laser and LED Safety Guidelines and Warnings
Overview
This table details the available LSZH-compliant breakout cables for the HDsystem.
Connector
Type
Description
MPO12 to 8
LC
The MPO12-8LC breakout cables connect four services on equipment
using LC plugs into equipment that uses a QSFP10/28 pluggable
transceiver or a plug with an MPO12 connector. The cable terminates
with an MPO12 connector at one end and four duplex LC connectors at
the other end.
The MPO12 connector and cable contain 12 fibers, in which four are for
the transmit direction and four are for the receive direction. The remaining
four fibers are not used.
The MPO12-8LC breakout cables are available in different lengths and are
either single-mode and multimode cables.
MPO24 to
24 LC
The MPO24-24LC breakout cables connect twelve services on
equipment using LC plugs into equipment using a plug with an MPO24
connector. The cable terminates with an MPO24 connector at one end
and twelve duplex LC connectors at the other end.
The MPO24 connector and cable contain 24 fibers, in which twelve are for
the transmit direction and twelve are for the receive direction.
The MPO24-24LC breakout cables are available in different lengths and
are single-mode cables.
229 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
