Accessory Installation Requirements
Chapter 7
Accessories
Accessory Installation Requirements 162
Air Filter Pads 165
Front Cover Extension Kits 165
Guide Rail Kits 167
Mounting Bracket Kits 170
Shelf Front Covers 172
Side Air Covers 173
Slot Covers 174
Cable and Fiber Trays 175
l Cables
l SH12 Shelf
l SH4R Shelf
l SH4R-2 Shelf
l SH1R Shelf
Accessory Installation Requirements
Before you begin the installation of your HDshelf, it is important to understand and
adhere to the accessory requirements for your particular installation.
These tables detail the accessory installation requirements for these shelves. In the
tables, the shelf column creates a category for each of the accessories.
Shelf Accessory
Requirements
19-inch 23-inch ETSI 300-mm
Depth
ETSI 600-
mm Depth
SH12 (cables w/MPO
connectors)
Side air covers Required Required Removed Required
Upper front cover Optional Optional Optional Optional
Lower front cover Required
1
Required
1
Required
1
Required
1
Front cover extension Required
2
Required
2
Required
2
Required
2
Table 92: Accessory Requirements — Open Rack Installations
