Fiber Optic Cables and Accessories
Fiber Optic Cables and Accessories
Patch Cables 227
Breakout Cables 229
To ensure faultless operation of the HD system, use only fiber-optic
cables that ADVA Optical Networking releases and provides. Fiber-
optic cables other those that ADVA Optical Networking releases and
provides might be incompatible with HD modules, and we cannot
guarantee interoperability.
l Handling Fiber-Optic Cables
l Shelf Cable Capacity
l Shelf Cable Capacity
l Laser and LED Safety Guidelines and Warnings
Patch Cables
Overview 227
LC Patch Cables 228
MPO12 Patch Cables 228
l Handling Fiber-Optic Cables
l Cable Management Best Practices
l Shelf Cable Capacity
l Laser and LED Safety Guidelines and Warnings
Overview
This table details the available patch cables for the HDsystem. These cables connect
the ECM and the traffic modules, and also connect traffic modules to breakout trays.
Connector
Type
Description
LC The LC patch cables connect equipment using LC plugs at both ends.
The cable terminates with a duplex LC connector at each end.
The LCpatch cables are available in different lengths and are single-
mode cables.
227 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
