Cable and Fiber Trays
Features
l Hinged front cover
l Modular extensible design, based on the 19-inch format
l Removable fiber fingers for flexible implementation based on your configuration
l Robust, low-profile housing made from alloyed steel sheet
l Access to the fiber optic tray from the front of the shelf
l Cable Management Best Practices
l Overview
Cable Capacity
The number of cables that the TR1 can store depends on the cable dimensions and
lengths. This table provides the recommended values when the installation has only one
opening between the fiber fingers. If you remove the fiber fingers, the capacity increases.
Optical Connector Dimension Max. Cable Number
MPO 3.5 mm (0.138 in.) 55 cables
MPO 3 mm (0.118 in.) 69 cables
LC 2 mm (0.079 in.) 180 cables
Table 98: Recommended Values for the Capacity of the TR1
l Cable Management Best Practices
l Overview
Shipment Contents
Each TR1 shipment consists of these components and accessories:
l TR1
l Mounting brackets — 19-inch installed; 23-inch and ETSI included
l TR1 Shelf
l Accessories
l Unpacking and Inspecting the Shelves and Components
l Electrostatic Discharge Damage Prevention and Warning
