Adva 3000R7 - Qsfp10;43 G;Sr4;MM;Mpo; Overview; Features

QSFP Optical Transceivers
QSFP10/43G/SR4/MM/MPO
Overview 141
Features 141
Specifications 142
Overview
Parameter Value Notes
Sales item number 1061800774-01
Release introduced FSP3000R7 Release
17.1
Fiber Multimode
Optical connector MPO12
Weight 200 g (7.1 oz)
Temperature range 0 to 70°C (32 to 158°F)
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
Table 74: General Information — QSFP10/43G/SR4/MM/MPO
l Pluggable Transceiver Compatibility
l MTBF Hours for HDEquipment
l Handling Pluggable Transceivers
Features
l Supports one bidirectional optical interface with four optical wavelengths (gray)
l Transports one aggregate service through four optical lanes
l Transports four services through four optical lanes
l Has a separate fiber per optical lane with an MPO12 connector
l Overview
l Specifications
l MTBF Hours for HDEquipment
141 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
