TR1 Shelf 175
Keep fiber-optic cables organized. If you do not use your rack posts for
fiber management, ADVA Optical Networking strongly recommends that
you use a cable and fiber tray.
TR1 Shelf
Overview 175
Features 177
Cable Capacity 177
Shipment Contents 177
Overview
The TR1 is a rack-mountable, fiber management shelf. It includes 11 separate,
removable cable fingers to accommodate your configuration needs. Typically you mount
the TR1 below a shelf so that it can efficiently manage and store the optical fibers and the
electrical and power cables as needed.
Figure 49: TR1 Shelf — Front View
The left and right sides of the shelf have hinges to help you install the TR1 so that the
front cover opens up or down, depending on your needs.
175 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
