Installing the FTM-3 in the SH1R
Installing the FTM-3 in the SH1R
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module are properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Stand behind the shelf, and then hold the FTM-3 upright with the faceplate toward
you (Mod LEDis on the bottom right).
3. Insert the FTM into the appropriate slot.
4. Gently apply pressure to the faceplate while you push the module into the slot.
5. Push on the faceplate to fully seat the module. The module is completely inserted
when its faceplate is flush with the back plate of the shelf.
6. After you have completely inserted the FTM-3, hand-tighten the thumb screws to
prevent inadvertent dislodging.
7. Use a Torx T10 screwdriver to gently tighten the retaining screw as needed. Do not
overtighten.
8. Repeat this procedure for the other FTM-3 in your SH1R.
l Electrostatic Discharge Damage Prevention and Warning
l FTM-3
l SH1R Shelf
303 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
