Installing the Mounting Brackets on a 1U Shelf
Figure 72: Example — 23-Inch Mounting Brackets Attached to Guide Rails
Save the remaining mounting brackets and packaging material for future
use.
l Installation Overview — SH1R Shelf
l Site Preparation Checklist
Installing the Mounting Brackets on a 1U
Shelf
In this procedure, 1U shelf refers to these components:
l TR1
For procedures for the SH1R, see Installing the Mounting Brackets on
SH1R Guide Rails.
This procedure assumes that:
l The shelf is unpacked and inspected;
l It is damage-free; and
l The shelf is on a static-dissipative mat.
