SH4R Shelf
If you install the SH4R in a cabinet, keep in mind that a single,
populated SH4R needs a minimum airflow of 360 CFM. See
Supported Rack Requirements for important supported installation
features and requirements.
l Clearance Requirements
l Heat Dissipation
l FTM-4
l Air Filter Pads
Power
The HDsystem supports a centralized power-supply architecture. The PSMs convert the
external DC or AC power to internal 12 VDC, which the system distributes to all modules
through the backplane.
The PSMs work in a redundant power configuration and supply the required power to the
shelf in a load-sharing mode. If a PSM fails, the remaining PSMs continue to supply
power to the entire shelf. You can then replace the failed PSM.
Type Configuration Slots
PSM1 PSM2 PSM3
Redundant 1+1 PSM-AC4 PSM-AC4 —
PSM-AC5 — PSM-AC5
PSM-DC4 PSM-DC4 —
PSM-DC4 — PSM-AC5
2+1 PSM-AC4 PSM-AC4 PSM-AC4
PSM-DC4 PSM-DC4 PSM-DC4
PSM-DC4 PSM-DC4 PSM-AC5
Non-redundant 1+0 PSM-AC4 — —
PSM-AC5 — —
PSM-DC4 — —
2+0 PSM-AC4 PSM-AC4 —
PSM-DC4 PSM-DC4 —
Table 7: SH4R Supported Power Configurations
The PSM-AC5 alone does not support a 2+0 or 2+1 configuration.
49 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
