QSFP Optical Transceivers
l EEPROM of each fiber-optic transceiver includes information about the transceiver
itself such as vendor code, wavelength, data rates and other relevant factory
parameters. It also includes information specifically from the ADVA Optical
Networking device code, serial number, and so forth. You can query the transceiver to
make sure it is the right one for the intended application.
l On-board digital diagnostics that provide remote monitoring capability
l Measurements and real-time monitoring of:
o
Rx optical input power (analog) [dBm]
o
Tx optical output power (analog) [dBm]
o
Transceiver temperature (analog) [C]
o
Transceiver supply voltage (analog) [mV]
l Laser and LED Safety Guidelines and Warnings
l Overview
l Color Coding
Color Coding
The color of the pull-tab latch determines the type of QSFP28 pluggable transceiver.
Beige
l QSFP28 SR4
Green
l QSFP28 CWDM4
Blue
l QSFP10 LR4, 4LR
l QSFP28 LR4
White
l QSFP28 PSM4 1550 nm
Yellow
l QSFP28 PSM4 1310 nm
Black or beige
l QSFP10 SR4
Purple
l QSFP28/112G
l Pluggable Transceiver Compatibility
l Naming Conventions
l Features
l Overview
135 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
