Overview
This chapter provides details about the HD infrastructure modules. This table provides
details about each available HD shelf and the associated infrastructure modules.
Shelf Infrastructure Modules
Management Power Cooling
SH12
l CEM-2
l ECM-2
l PSM-AC6
l PSM-DC
l FTM-2
SH4R
l CEM-4
l ECM-2
l PSM-AC4
l PSM-AC5
l PSM-DC4
l FTM-4
SH4R-2
l CEM-4
l ECM-2
l PSM-AC4
l PSM-AC5
l PSM-DC4
l FTM-4
SH1R
l CEM-3
l ECM-3
l PSM-AC3 l FTM-3
