Installing the CEM
Installing the CEM
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module are properly inspected.
The CEM-3 does not have locking levers.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the CEM with the faceplate toward you and the levers extended.
3. Align the CEM edges with the guides of the shelf slot.
4. Lift out the levers, and then gently apply pressure to the bottom of the faceplate while
you push the module into the slot.
5. Push on the faceplate to fully seat the module.
6. Press down on the locking levers to secure the module and connect it to the
backplane. The module is completely inserted when its faceplate is flush with the
shelf panels.
7. After you have completely inserted the CEM, hand-tighten the thumb screws to
prevent inadvertent dislodging.
8. Use a Torx T10 screwdriver to gently tighten the thumb screw(s). Do not overtighten.
l Electrostatic Discharge Damage Prevention and Warning
l CEM-2
l CEM-4
l CEM-3
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 300
