Adva 3000R7 - Cooling and Airflow

SH1R Shelf
Figure 20: SH1R Slot Numbering — Rear View
l Overview
l Infrastructure Modules
Cooling and Airflow
This figure provides visual details about the SH1R cooling and airflow.
Figure 21: Top View of Airflow through the SH1R
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 68
