Air Filter Pads
Air Filter Pads
It is mandatory that air filter pads are in use at all times to prevent dust and debris from
entering the shelf. The pad is included with the air filter unit. For shelves, access to the
replaceable air filter is at the bottom of the shelf. For the PSM-AC6, access to the
replacement air filter is on the front of the module.
A dirty air filter pad negatively influences cooling efficiency. Replace
dirty air filter pads at least once a year. ADVA Optical Networking
recommends replacing the air filter pad every 90 days in
environments without air filtration.
Component Air Filter Pads Sales Item Number
SH12 SA-AF-SH12:Contains 20 air filter pads - 10
for each air filter (one below the modules and
one in the lower front cover) and 40 air filter
pads for the PSM-AC6
1013800024-01
SH4RandSH4R-
2
SA-AF-SH4: Contains 10 air filter pads 1013800054-01
SH1R SA-AF-SH1R:Contains 10 air filter pads 1013800066-01
Table 94: Available Air Filter Pads
Always keep extra air filters available and order more when your supply
starts to run low.
l Replacing the Air Filter Pads
l Cooling and Airflow — SH12
l Cooling and Airflow — SH4R
l Cooling and Airflow — SH4R-2
l Cooling and Airflow— SH1R
Front Cover Extension Kits
The front cover extension increases the cabling space between the module faceplates
and the SH12, SH4R, and SH4R-2 shelf front cover.
If you plan to install a front cover on your HD shelf and you use cables
with MPOconnectors, you must also install the front cover extension. To
determine if your shelf rack or cabinet configuration supports front covers
and extensions, and for more information about accessory installation
requirements, see Accessory Installation Requirements.
165 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
