Unpacking an SH4R and SH4R-2 Shelf
9. Remove the ESD protective bag from the shelf and lay it aside.
10. Verify that you have the proper shelf type, using the Product IDLabel for
identification.
11. Open the accessory kits and boxes that contain the cables, documentation, and
management software. Do not use a knife to open these boxes.
12. Visually check the shelf and accessories for external damage. If identified, make
note of any damaged or missing items.
13. Verify that you have all of the necessary equipment, cables, documentation, and so
forth by comparing the your shipment's packing slip to your purchase order copy.
Some shelves are ordered preconfigured according to specific
requirements. Differences between your site planning and the delivered
configuration may occur caused for example by last-minute changes.
14. If any items are missing or you need additional information, notify your customer
service representative or ADVA Optical Networking immediately.
Each shelf comes with two 19-inch rack-mounting brackets preinstalled
and each unoccupied shelf slot is filled with the appropriate slot cover.
15. Save the packaging material until the operational checkout of the HD equipment is
complete. Storing all the shipping boxes and packaging material enables the HD
components to be repacked for a possible transport to another installation site or to
be returned for a needed repair.
l Shipment Contents — SH12
l Qualified Personnel Warning
l Shelf Lifting and Moving Guidelines
l Handling Equipment Precautions and Guidelines
l Electrostatic Discharge Damage Prevention and Warning
Unpacking an SH4R and SH4R-2 Shelf
Each SH4R or SH4R-2 shelf is securely packaged in a shipping box. Depending on how
you ordered your system, your shelf may ship empty or with a minimum number of
modules installed.
1. Attach a ground strap to your wrist and snap the ground wire to the wrist band. Insert
the ground plug into a grounded ESD jack.
2. Inspect the shipping boxes for evidence of damage during shipment. Claims for
damage during shipment must be asserted promptly with the transportation company
involved. If any damage or other signs of mishandling are evident, inform both the
247 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
