Adva 3000R7 - Replacing a PSM-AC6

Replacing a PSM
8. If the dedicated AC power source outlet has a power switch, set it to the ON (|)
position to power on the system for the first time.
The Mod LED of the first PSM should turn green to indicate that the units are
functioning properly.
9. Refer to the appropriate software guide to reprovision the new PSM-AC5s.
If the Mod LED of the PSM is off, no power is being supplied to the unit. In
case of an error, the Mod LED turns red. For troubleshooting information,
see Troubleshooting with Component LEDs or contact ADVA Optical
Networking for technical assistance.
l Electrostatic Discharge Damage Prevention and Warning
l PSM-AC4
l PSM-AC5
l Handling Modules
l AC Power Source Requirements
l Electrical Safety Guidelines and Warnings
l In Case of Electrical Accident
Replacing a PSM-AC6
ELECTRIC VOLTAGEWARNING
Before connecting the ACpower cable, ensure that power is
removed from the dedicated AC supply circuit.
This procedure assumes that:
l No voltage is present;
l You properly grounded the shelf to the rack; and
l You unpacked and properly inspected the replacement module.
To remove the module:
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. Verify that the power source is disconnected from the PDU.
3. Remove the ACpower cable plug from the dedicated ACpower source outlet.
4. Remove the ACpower coupler(s) from the PSM.
5. Use a Torx T10 screwdriver to unscrew the retaining screw from the PSM.
6. Grasp the handle, and then slowly slide the PSM out of the shelf until the Mod LED is
unlit.
7. Place the defective PSM on a static-dissipative mat.
433 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
