Adva 3000R7 - Grounding

SH12 Shelf
Type Configuration Slots
PSM1 PSM2 PSM3 PSM4
Non-redundant 1+0 PSM-DC — — —
PSM-AC6 — — —
2+0 PSM-DC — — PSM-DC
PSM-AC6 — — PSM-AC6
3+0 PSM-DC PSM-DC — PSM-DC
PSM-AC6 PSM-AC6 — PSM-AC6
Table 4: SH12 Supported Power Configurations
Shelf power is provided by –48 VDC input from redundant A and B battery feeds. The
power feeds are located on the bottom front of the SH12. Each power supply has its own
A and B backplane feed. Each input feed has its own –48 V fail detection.
When the SH12 configuration is for front DC operation, it uses the power feed module
(PFMF). This module is passive and connects the –48 VDC at the front of the shelf to the
backplane. It contains additionally passive power filters for the –48 VDC.
For ACpower, connect the AC power cables connect directly to the front of the power
supply.
l AC Power Source Requirements
l DCPower Source Requirements
l General Power and Grounding Guidelines
l Electrical Safety Guidelines and Warnings
l PSM-AC6
l PSM-DC
Grounding
The SH12 contains these ground terminals and connectors:
l Chassis ground
l Signal ground
l Strap for a 2-zone or 3-zone configuration
l ESD ground
The signal ground and 3-zone ground configuration are currently not
supported.
37 FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B
