Adva 3000R7 - North America Cables

Power Cables
Two Conductor Gray-Blue DC Power Cables
Gray Insulation Blue Insulation
Wire Function DCnegative conductor DC positive conductor
Voltage –48 V 0 V (return)
Use to negative (–) terminal to positive (+) terminal
Cable Variant Sales Item
Number
Wire Gauge Compatible
PSM
Connector Type
(equipment end)
CBL/DC/0300/4AWG10/SUB-D/GR-BL 1036800023 10 AWG
l PSM-DC
1
4-pin D-SUB
CBLZ/DC/0300/2AWG8/TB/GR-BL 1036800041 8 AWG
l PSM-DC4
2-hole T&B or Burndy
plated copper lugs
CBLZ/DC/3M/2AWG8/SUB-D2/GR-BL 1036800047 8 AWG
l PSM-DC
2
l PSM-DC4
2-pin D-SUB
North America Cables
Two Conductor Red-Black DC Power Cables
Red Insulation Black Insulation
Wire Function DCnegative conductor DC positive conductor
Voltage –48 V 0 V (return)
Use to negative (–) terminal to positive (+) terminal
Cable Variant Sales Item
Number
Wire Gauge Compatible
PSM
Connector Type
(equipment end)
CBL/DC/0300/4AWG8/SUB-D/RD-BK 1036800025 8 AWG
l PSM-DC
1
4-pin D-SUB
CBL/DC/0300/2AWG6/TB/RD-BK 1036800042 6 AWG
l PSM-DC4
2-hole T&B or Burndy
plated copper lugs
CBLZ/DC/3M/2AWG8/SUB-D2/RD-
BK
1036800048 8 AWG
l PSM-DC
2
l PSM-DC4
2-pin D-SUB
1
Use with SH12 (HWVer. 01)
2
Use with SH12 (HW Ver. 02)
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 216
