Adva 3000R7 - Grounding Cables; Grounding Cable - SH12

Grounding Cables
Shelf Quantity
SH12 280
SH4R and SH4R-2 98
SH1R (left side) 30
SH1R (right side) 28
Table 102: Recommended Values for MPO12-type Cables (3 mm)
Shelf Quantity
SH12 100
SH4Rand SH4R-2 44
SH1R (left side) 15
SH1R (right side) 12
Table 103: Recommended Values for MPO24-type Cables (4.5 mm)
l Cable Management Best Practices
l Fiber Optic Cables and Accessories
l SH12 Shelf
l SH4R Shelf
l SH4R-2 Shelf
l SH1R Shelf
Grounding Cables
Grounding Cable — SH12 210
Grounding Cable — SH4R and SH4R-2 211
Grounding Cable — SH1R 211
Grounding Cable — SH12
The SH12 ships with this grounding cable:
l Shelf grounding cable for SH12 HW Rev. 2.0 (CBLZ/GND/0100/1AWG6/TB/GN-YL -
Sales Item Number 1036800031)— 6 AWG, 100 cm length, green/yellow. Equipment
end:straight 2-hole M6 ring lug. Rack end:straight 2-hole M6 ring lug. LSZH
compliant. Appropriate screws and washers are included.
l Shelf grounding cable for SH12 HW Rev. 1.0 (CBL/DC/0100/1AWG4/TB/GN-YL - no
longer orderable) — 4 AWG, 100 cm length, green/yellow. Equipment end:straight 2-
hole M5 ring lug. Rack end:straight 2-hole M5 ring lug. Appropriate screws and
washers are included.
You can also order the grounding cables separately.
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 210
