Adva 3000R7 - Installing the Infrastructure Modules

Chapter 22
Installing the Infrastructure Modules
Required Tools and Equipment 299
Installing the CEM 300
Installing the ECM 301
Installing the FTM-2 in the SH12 302
Installing the FTM-3 in the SH1R 303
Installing the FTM-4 in the SH4R and SH4R-2 304
Installing the PSM-AC6 in the SH12 305
Installing the PSM-DC in the SH12 306
Installing the PSM-AC4 or PSM-AC5 in the SH4Rand SH4R-2 307
Installing the PSM-DC4 in the SH4Rand SH4R-2 308
Installing the PSM-AC3 in the SH1R 309
For the SH12, the protection plate must be removed before installing
modules.
Use care when installing modules in a shelf. Ensure the modules are
properly aligned with the appropriate slot guides. Do not force a
module into a slot or onto the backplane connectors. If you are having
problems installing a module without using excessive force, stop
immediately and contact Technical Services.
Never reach into a vacant shelf slot. Contact with the adjacent
modules or the connectors on the backplane could result in damage
to the equipment. Exposed circuitry could also constitute an energy
hazard.
Risk of electromagnetic disturbances!
Be careful not to damage the EMI shielding gasket on the module
faceplate edges when inserting it into the slot. Otherwise EMC
compliance cannot be achieved.
