Adva 3000R7 - Replacing an HD Traffic Module; Required Tools and Equipment; Removing a Traffic Module

Replacing an HDTraffic Module
Replacing an HDTraffic Module
Required Tools and Equipment 436
Removing a Traffic Module 436
Installing a Traffic Module 437
Required Tools and Equipment
l ESD-preventive wrist strap or other personal grounding device
l Suitable grounded surface or a static-dissipative mat
l Appropriate traffic module
l Appropriate slot cover, if not replacing the traffic module
l Dust cover for any open port
l Electrostatic Discharge Damage Prevention and Warning
l Laser and LED Safety Guidelines and Warnings
l Traffic Module Support
l Handling Modules
Removing a Traffic Module
To make it easier to reattach the cables, make sure they are labeled.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. If installed, remove the front cover from the shelf as described in Removing and
Installing Front Covers.
3. Disconnect the various cables.
4. If pluggable transceivers are installed, remove them as described in Removing a
Pluggable Transceiver.
5. Loosen the thumb screws.
6. Lift out on the locking levers to disconnect the module from the backplane.
7. Grasp the levers, and then carefully slide the traffic module out of the shelf.
8. Place the defective traffic module on a static-dissipative mat.
9. Return the defective traffic module to ADVA Optical Networking as described in
Returning Equipment.
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 436
