Installing the FTM-2 in the SH12
Installing the FTM-2 in the SH12
This procedure assumes that:
l The shelf is properly grounded to the rack; and
l The shelf and module are properly inspected.
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESDjack.
2. Hold the FTM-2 upright with the faceplate toward you.
3. Grasp the handle while inserting the FTM into the appropriate slot.
4. Gently apply pressure to the faceplate while you push the module into the slot.
5. Push on the faceplate to fully seat the module. The module is completely inserted
when its faceplate is flush with the faceplates of the adjacent modules and the shelf
panels.
6. After you have completely inserted the FTM-2, hand-tighten the thumb screws to
prevent inadvertent dislodging.
7. Use a Torx T10 screwdriver to gently tighten the retaining screw as needed. Do not
overtighten.
8. Repeat this procedure for the other two FTM-2s in your SH12.
l Electrostatic Discharge Damage Prevention and Warning
l FTM-2
l SH12 Shelf
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 302
