QSFP Optical Transceivers
Parameter Value Notes
Maximum laser off mode per
optical lane Tx power
–30 dBm
Power measurement accuracy ±3 dB
OPRmeasurement range –17.4 dBm to +3.5 dBm
Table 71: Specifications — QSFP10/11G/4LR/SM/MPO
l Overview
l Features
l MTBF Hours for HDEquipment
l Pluggable Transceiver Compatibility
QSFP10/43G/LR4/SM/LC
Overview 138
Features 138
Specifications 139
Overview
Parameter Value Notes
Sales item number 1061800770-01
Release introduced FSP3000R7 Release
17.1
Fiber Single-mode
Optical connector LC/PC
Weight 200 g (7.1 oz)
Temperature range 0 to 70°C (32 to 158°F)
Environmental standards
compliance
l Telcordia SR-3580 Level 3 (NEBS)
l ETSI EN 300 019-1-3 Class 3.1
Table 72: General Information — QSFP10/43G/LR4/SM/LC
l Pluggable Transceiver Compatibility
l MTBF Hours for HDEquipment
l Handling Pluggable Transceivers
Features
l Supports one bidirectional optical interface with four optical wavelengths (gray)
l Transports one aggregate service through four optical lanes
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 138
