Adva 3000R7 - Replacing a PSM-AC3

Replacing a PSM
l Electrostatic Discharge Damage Prevention and Warning
l PSM-DC4
l Handling Modules
l DCPower Source Requirements
l Electrical Safety Guidelines and Warnings
l In Case of Electrical Accident
Replacing a PSM-AC3
ELECTRIC VOLTAGEWARNING
Before connecting the ACpower cable, ensure that power is
removed from the dedicated AC supply circuit.
This procedure assumes that:
l No voltage is present;
l You properly grounded the shelf to the rack; and
l You unpacked and properly inspected the replacement module.
To remove the module:
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. Verify that the power source is disconnected from the PDU.
3. Remove the ACpower cable plug from the dedicated ACpower source outlet.
4. Remove the ACpower coupler from the PSM.
5. Use a Torx T10 screwdriver to unscrew the retaining screw from the PSM.
6. Grasp the handle and carefully slide the PSM out of the shelf.
7. Place the defective PSM on a static-dissipative mat.
8. Return the defective PSM to ADVA Optical Networkingas described in Returning
Equipment
To install the new module:
1. Verify that you are properly grounded with an anti-static wrist strap or heel strap
connected to the grounded ESD jack.
2. Verify that the power source is disconnected from the PDU.
3. Stand behind the shelf, and then hold the PSM upright with the faceplate toward you.
4. Insert the PSMinto the appropriate slot.
5. Gently apply pressure to the faceplate while you push the module into the slot.
6. Push on the faceplate to fully seat the module. The module is completely inserted
when its faceplate is flush with the back plate of the shelf.
FSP 3000R7 High-Density Subshelf Guide - R17.2 - Issue:B 428
